High Voltage Sf6 Circuit Breaker

Item:high voltage sf6 circuit breaker

The LW36-72.5 is an outdoor three-pole AC 50 Hz high-voltage circuit breaker, designed primarily for the protection of power transmission and transformation lines. It can also serve as a tie circuit breaker. This breaker is assembled on a frame, and operation is not possible with just one pole.

Features:
Excellent Arc Extinguishing Performance: SF6 gas provides outstanding electrical insulation and arc extinction.

Superior Breaking Performance: Delivers effective breaking capabilities with low operating noise.

Compact and Simple Design: The structure is straightforward and space-efficient.

Low Maintenance Workload: Maintenance requirements are minimal, with longer intervals between maintenance cycles.

Working Environment：

Item:high voltage sf6 circuit breaker

High-voltage SF6 circuit breakers are designed to operate effectively under a variety of environmental conditions. Key aspects of their working environment include:

Outdoor Installation:

These circuit breakers are typically installed outdoors and are designed to withstand weather elements such as rain, snow, and high humidity.

Temperature Range:

They can function effectively in a wide temperature range, often from -30°C to +40°C (-22°F to +104°F), depending on specific design standards.

Altitude:

SF6 circuit breakers are suitable for operation at high altitudes. However, performance may need to be adjusted at extreme elevations due to lower air density.

Pollution Levels:

Designed to resist the effects of environmental pollution, such as dust and salt, these breakers often have enhanced insulation and protective features

Main Technical Parameters

Structure And Mounting Dimensions

Possible causes of electrical circuit failure

Insulation Failure:

Deterioration of insulation materials can lead to breakdown, allowing electrical arcing or short circuits.

Gas Leakage:

Loss of SF6 gas due to leaks can compromise insulation and arc-extinguishing capabilities.

Mechanical Malfunction:

Issues with mechanical components, such as the operating mechanism or linkages, can prevent the breaker from functioning correctly.

Overcurrent or Overload:

Excessive current beyond the rated capacity can cause overheating and damage to the circuit breaker.

Product Real Shot

FAQ

A1:What is an SF6 circuit breaker?

Q1: An SF6 circuit breaker uses sulfur hexafluoride (SF6) gas as an insulating and arc-extinguishing medium to protect electrical circuits from overloads and faults.

A2: What are the key features of high-voltage SF6 circuit breakers?

Q2:Key features include excellent insulation and arc-extinguishing properties, compact design, low operating noise, and minimal maintenance requirements.

A3:What is the operating principle of an SF6 circuit breaker?

Q3:It operates by using SF6 gas to quench arcs that occur during circuit interruption, allowing for rapid and reliable disconnection of electrical faults.

A4:How does temperature affect the performance of SF6 circuit breakers?

Q4:SF6 circuit breakers are designed to operate effectively across a wide temperature range, but extreme temperatures may affect gas pressure and insulation properties.
